AP Series Pallets are the most popular Perforated top pallet with 3 Runners base, used in Selective Pallet Racking, Drive-in Racking System, Pallet Racking guided with Radio Shuttle and ASRS (Automated Storage and Retrieval System); it is used in large, medium, and small industry segment like automotive, Cosmetics, Detergent, Foodgrain & grocery storage, Returnable Multi-Trip pallets, etc. The versatile AP can be handled with all kinds of MHE. Its Perforated top & bottom inhibits effective Air flow distributions ventilation in the case of Food Grain storage, Cold Storage & Deep Freezer.
AP Series pallets are ideal for use in multipurpose use like Floor Application, Display, multiple stacking, Cold Store, Deep Freezer, food grain & grocery storage, Metal / Plastic Drums for oil & chemical Storage, Dynamic movement with the help of all types of MHE (Material Handling Equipment’s), Rack Storage, stringent & critical Racking application & conveyorized movements.
AP Series Pallets comes in different load capacity from 200 Kgs. to 1500 Kgs., load on the Racking system.
The most recent introduction in AP Series pallets is Galvanized Steel Tube Reinforcement, Base Runner Flat for Conveyorized movement & Radio shuttle movement, Use of Special Plastic Blend to ensure heavier load with minimal deflection in most critical Drive-in Racking system & also in controlled temperatures like a cold store and deep freezers.
AP Series Pallets in ASRS & Automated Conveyorized Movement:
Automated handling & storage systems can be disrupted due use of conventional plastic and wooden pallets for moving goods in the automated packaging area, causing delays in retrieval and cost. Nilkamal AP Series for Automated storage system is an obvious solution that perfectly complements automated handling systems. Nilkamal Injection Molded Plastic Pallet for Automation has easy access to Stacker Crane and easily moves on roller conveyors, chain conveyors, sortation equipment & robotic automation. Truly All-Purpose Pallet.
Some of the Nilkamal’s AP Series pallet models are listed below:
|
Nilkamal Pallet Model
|
Dimension
(L X W X H) in mm
|
Features
|
|
AP-1210 LW
|
1200 x 1000 x 160
|
100% Plastic blend with rack load upto 300 kg,
|
|
AP-1210 MW
|
1200 x 1000 x 160
|
100% Plastic blend with rack load upto 750 kg,
|
|
AP-1210 HW
|
1200 x 1000 x 160
|
100% Plastic blend with rack load upto 1000 kg,
|
|
AP-1210 HW NEP
|
1200 x 1000 x 160
|
100% Plastic blend with rack load upto 1200 Kg., on Selective Racking system & 1000 kg, on Drive-in Racking system
|
|
AP-1208 S8
|
1200 x 800 x 150
|
Plastic blend with Galvanized Steel Tube Reinforced for Racking load upto 1500 kg.,
|
|
AP-1210 S8
|
1200 x 1000 x 150
|
|
AP-1012 S8
|
1200 x 1000 x 150
|
|
AP-1212 150 S8
|
1200 x 1200 x 150
|
|
AP-1210 MWI S8RTC
|
1200 x 1000 x 166
|
Plastic blend with Galvanized Steel Reinforcement and special Runners base close deck for Automated Racking system and conveyorized movement
|
|
AP-1212 170 S8RTC
|
1200 x 1200 x 170
|
|
AP-1012
|
1200 x 1000 x 150
|
100% Plastic blend with rack load upto 500 kg,
|
|
AP-1212 150
|
1200 x 1200 x 150
|
|
AP-1208
|
1200 x 800 x 150
|
|
AP-0606
|
660 x 660 x 130
|
100% Plastic blend with rack load upto 300 kg., and exclusive for Tiles Storage, Shopping mall display and drums handling
|
