Spill Pallet with Lid

Product Description:

Nilkamal's Spill Containment Pallets are an absolute must for food & pharma companies. Spillage can occur anywhere / any time & can contaminate sensitive food & pharma products or clean rooms, causing huge rejections & recalls. Nilkamal's Spill Containment Pallets are made to international standards and & are an absolute necessity for your pharma or food manufacturing set-up.

SPILL PALLET MODEL	CAPACITY OF DRUMS / NO. OF DRUMS	SUMP CAPACITY	DIMENSION (L X W X H) MM	STATIC	DYNAMIC
RPF50LSPIL1*	210 Ltrs / 1 Drum	50 Ltrs.	1050 X 650 X 175	500 Kg.,	NA
RPF120L3RSPIL2*	210 Ltrs / 2 Drums	120 Ltrs.	1400 X 800 X 270	500 Kg.,	500 Kg.,
RPF200L3RSPIL2*	210 Ltrs / 2 Drums	200 Ltrs.	1400 X 800 X 420	500 Kg.,	500 Kg.,
RMPCF100L3RSPIL*	210 Ltrs / 4 Drums	100 Ltrs.	1300 X 1300 X 200	1000 Kg.,	1000 Kg.,
RPF240L3RSPIL4*	210 Ltrs / 4 Drums	240 Ltrs.	1400 X 1400 X 270	1000 Kg.,	1000 Kg.,
RMPCF525L3RSPIL**	210 Ltrs / 4 Drums	525 Ltrs	1300 X 1300 X 570	2000 Kg.	1000 Kg.,

* Above spill Containment pallet can be provided with Drain plug/outlet facility on request

** RMPCF525L3RSPIL-4 has an inbuilt drain plug/outlet for draining our spilled oil/chemical stored inside the sump

* FRP GRATING Price increase due to input cost increased

Product Detail:

Capacity: 50 LTR Approx.

Static Load (UDL): 500 KG

Outer Dimension: 1050(L) x 650(W) x 175(H) MM Approx.
